Hydraulic General Purpose Cylinder

Hydraulic General Purpose Cylinder Specification

Temperature
-20C to 65C

Wall Thickness
8 mm

Capacity
10 Ton

Pressure
700 bar (max)

Material
High strength alloy steel

Structure
Single acting, spring return

Power
Hydraulic

Dimensions
90 mm diameter x 250 mm length

Max. Stroke
155 mm

Shaft Diameter
40 mm

Seals Type
Polyurethane and NBR seals

Rod
Hard chrome plated steel

Weight
18 kg

Oil Capacity
0.8 litres

End Connection
Threaded port for hydraulic hose

Tensile Strength
Min 950 MPa

Test Pressure
900 bar

Usage
Industrial lifting, pushing, pulling, bending

Surface Treatment
Black oxide finish

Return Type
Spring return

Paint
Anti-corrosive paint finish

Mounting Type
Flat base with bolt holes

Port Size
3/8" NPT

Hydraulic General Purpose Cylinder Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About Hydraulic General Purpose Cylinder

Utilise this top-tier Hydraulic General Purpose Cylinder, famed for its robust design and redoubtable performance in demanding industrial environments. Featuring a flat base with bolt holes for stable mounting, this popular cylinder offers a spectacular combination of strength and versatility, thanks to its high-strength alloy steel construction and spring return mechanism. Boasting a 10-ton capacity, 700 bar pressure, and tested up to 900 bar, it is equipped with polyurethane and NBR seals for leak-proof reliability. Notable features include a black oxide finish, anti-corrosive paint, and a hard-chrome plated steel rod. Perfect for lifting, pushing, pulling, and bending tasks in India and beyond.

Precision Engineering for Industrial Versatility

The Hydraulic General Purpose Cylinder delivers exceptional reliability and performance for lifting, pushing, pulling, and bending operations across a wide spectrum of industries. Its robust build, flat base, and secure bolt holes make it ideal for installation on presses, jigs, heavy machinery, and structural frameworks. The black oxide and anti-corrosive finishes ensure longevity in harsh settings, making it a preferred choice for manufacturing plants, construction sites, and mechanical workshops.

Secure Packaging and Reliable Worldwide Dispatch

Each Hydraulic General Purpose Cylinder is carefully dispatched in rugged, industrial-grade packaging to ensure safe handover and minimal transit risk. Our established processes cater to the export market, particularly across Asia, Africa, and the Middle East. With remarkable supply ability, we ensure prompt dispatching and efficient handover to logistics partners, meeting the demands of bulk or repeat orders. Trust us for timely dispatch and reliable delivery worldwide.

FAQ's of Hydraulic General Purpose Cylinder:

Q: How is the Hydraulic General Purpose Cylinder typically used in industrial applications?

A: This cylinder is primarily utilised for industrial lifting, pushing, pulling, and bending operations, making it a versatile choice for manufacturing, construction, and heavy equipment maintenance.

Q: What makes the black oxide finish and anti-corrosive paint beneficial for the cylinder?

A: The black oxide surface treatment and anti-corrosive paint impart enhanced resistance to corrosion and wear, significantly increasing the operational lifespan even in challenging environments.

Q: Where can this hydraulic cylinder be mounted?

A: Thanks to its flat base with bolt holes, the cylinder can be securely mounted onto presses, baseplates, jigs, or industrial machinery frameworks for stable and safe operation.

Q: What is the process for handover and dispatch of the hydraulic cylinder?

A: Each cylinder is dispatched in durable packaging, and our streamlined process ensures prompt handover to trusted logistics partners for safe and efficient delivery worldwide.

Q: When is it recommended to utilise this cylinder's 10-ton capacity?

A: This cylinder is best utilised when demanding high-load applications requiring up to 10 tons of force, such as heavy lifting and industrial forming, where reliability is paramount.

Q: What type of seals are used in this cylinder and why are they important?

A: The cylinder is equipped with polyurethane and NBR seals, which are crucial for ensuring leak-proof performance and maintaining pressure stability during prolonged use.
